SKF bearing vibration and temperature inspection

Source:  skf bearing  Time:  2020-11-10

SKF bearing vibration is very sensitive to bearing damage, such as peeling, indentation, rust, cracks, wear, etc. will be reflected in the deep groove ball bearing vibration measurement, so, by using a special bearing vibration measuring device (frequency analyzer, etc.) The size of the vibration can be measured, and the specific circumstances of the abnormality cannot be inferred from the frequency points. The measured value differs depending on the use condition of the bearing or the installation position of the sensor, etc. Therefore, it is necessary to analyze and compare the measured value of each machine in advance to determine the judgment standard.
The temperature of the SKF bearing can generally be inferred from the temperature outside the bearing. It is more appropriate if the oil hole can be used to directly measure the temperature of the outer ring of the bearing.
Generally, the temperature of deep groove ball bearings slowly rises as the bearings start to run, and reaches a steady state after 1-2 hours. The normal temperature of the bearing varies with the heat capacity, heat dissipation, speed and load of the machine. If the lubrication and installation are not suitable, the bearing temperature will rise sharply and the SKF bearing will have abnormally high temperature. At this time, the operation must be stopped and necessary precautions must be taken.
The thermal sensor can be used to monitor the working temperature of the bearing at any time, and to automatically alarm or stop when the temperature exceeds the specified value to prevent burning shaft accidents.
High temperature often indicates that the bearing is in an abnormal condition. High temperatures are also not conducive to bearing lubricants. Sometimes overheating of deep groove ball bearings can be attributed to bearing lubricants. Long-term continuous rotation of bearings at temperatures exceeding 125 ° C will reduce bearing life. The causes of high-temperature bearings include: insufficient lubrication or excessive lubrication, impurities contained in the lubricant, excessive load, bearing damage ring, insufficient clearance, and high friction generated by the oil seal, etc.
Therefore, it is necessary to continuously monitor the temperature of deep groove ball bearings, whether it is to measure the bearings themselves or other important parts. If the operating conditions remain unchanged, any temperature change may indicate that a failure has occurred.
Bearing temperature can be measured regularly with the help of a thermometer, such as a digital thermometer, which can accurately measure the bearing temperature and display it in units of degrees Celsius or Fahrenheit.
The important bearing means that when it is damaged, it will cause the equipment to stop, so it is best to install a temperature detector for this type of deep groove ball bearing.
Under normal circumstances, SKF bearings will have a natural temperature rise immediately after lubrication or relubrication and last for one or two days.Buy good SKF Bearings .click here.
As an important part, the bearing must always pay attention to its use and prevent the occurrence of bad conditions. Daily maintenance is very important, so that it can also increase its service life.
Click here to know more about SKF Bearing

Prevention of foreign matter in assembly: When SKF bearings are installed on the rotor for dynamic balancing, it is easy to enter the iron filings generated during dynamic balancing into the SKF bearings, so it is best to perform dynamic balancing before installing the bearings. For the convenience of assembly, some manufacturers apply some oil or grease to the SKF bearing chamber for lubrication effect during assembly, but it is often difficult for the operator to control the amount. If the oil or grease accumulates in the SKF bearing chamber a lot, the SKF bearing It is easy to enter the SKF bearing along the shaft when rotating. It is best not to apply oil or grease to the SKF bearing room. If it must be painted, it must be controlled and there must be no accumulation in the SKF bearing room.

Prevention of lacquer rust: The characteristic of lacquer rust is that it mostly occurs in sealed motors. The sound of the motor is very good during assembly, but after some time in the warehouse, the abnormal noise of the motor becomes very large, and the removal of the SKF bearing is serious Rust phenomenon. In the past, many manufacturers thought it was the problem of SKF bearings. After our continuous publicity, now the motor factory has realized that it is mainly the problem of insulating paint. This problem is mainly because the acidic substance volatilized from the insulating paint forms corrosive substances under a certain temperature and humidity, which causes the SKF bearing to be damaged after corroding the SKF bearing groove. At present, the problem can only be to select a good insulating paint and ventilate for a period of time after drying and assembly.
